Hotel Mobile Electronic Screen Stand

The hotel mobile electronic screen stand is a floor-standing movable screen support system tailored for the hospitality industry. Different from wall-mounted brackets, it removes the limitation of fixed screen positions. Four 360°silent universal casters with dual brake systems are mounted on four corners of the base, enabling smooth pushing and stable parking. The stand height and screen tilt angle are adjustable, so the display can be transferred freely among guest rooms, meeting rooms, banquet halls, lobbies and other areas.

Five Major Pain Points in Hotel Scenarios & Corresponding Solutions

Core Functions

✅Flexible Movement for All Scenarios

Four sets of 360°silent universal casters are equipped, with two or four independent brakes. It slides smoothly and stays fixed once braked. The screen can be moved to any hotel area as needed, maximizing equipment utilization with one screen serving multiple venues.

✅Adjustable Height for All Crowds

Adopting sleeve telescopic columns or pneumatic lifting structure with an 800–1500mm adjustment range. The height can be set to the optimal viewing level for standing meetings, seated training or children’s activities based on screen size and viewers.

✅Multi-angle Adjustment to Eliminate Light Reflection

The screen bracket supports tilt adjustment from -5°to +15°and left-right rotation within±20°. It can avoid light reflection from windows or corners to guarantee clear viewing from all directions.

✅Sturdy Load-bearing for Large Screens

Constructed with thick cold-rolled steel plates and aluminum alloy columns. The standard load capacity ranges from 60kg to 80kg, and upgraded models support over 90kg, fitting mainstream 32–75-inch hotel screens; certain versions support up to 100-inch displays.

Technical Parameters

Installation Steps

1. Take out columns, base, hanging brackets and accessories from the package, and check all parts for completeness.

2. Fix the column to the base with screws and lock casters on four corners of the base tightly.

3. Adjust the horizontal width of the hanging bracket according to the VESA holes on the back of the screen, then fix the bracket to the screen with matched screws.

4. Hang the screen with bracket onto the installation slot of the column, lock the safety bolt after full engagement of hooks.

5. Connect power cords and signal wires, store all cables inside the column’s cable channel and cover the cable plate.

6. Adjust height to the proper position and lock the knob; tune screen tilt and rotation angle for comfortable viewing.

7. Test sliding smoothness of the stand, check stability after braking, and put into use after confirmation.

Applicable Scenarios & Recommended Configurations

Hotel Mobile Electronic Screen Stand vs Ordinary TV Cart

Operation & Maintenance Guide

Installation Steps

1. Unfold the foldable base and tighten fixing screws.

2. Install four casters on four corners of the base and lock nuts.

3. Insert the column into the base connector and fasten with bolts.

4. Mount the crossbeam on the column and adjust its width to match screen VESA holes.

5. Fix hooks on the screen back and hang the screen onto the crossbeam.

6. Thread all cables through the inner column and lead them out from the bottom outlet.

7. Loosen the locking handle to adjust height, then lock it after setting the proper level.

Daily Usage Notes

•Before moving: Release caster brakes completely.

•When parked: Step down brakes on two casters to secure the stand.

•Height adjustment: Recommended two-person operation, one holding the screen and the other adjusting height.

•Regular inspection: Check caster screws and lifting locking parts for looseness every 3 months.

FAQ

Q1: What screen sizes can the hotel mobile electronic screen stand support?

A: Standard models fit 32–65-inch screens, while upgraded versions support 75-inch up to 100-inch displays. Provide your screen size and weight before ordering for matched model recommendation.

Q2: Does it slide smoothly and scratch floors?

A: Equipped with 360°silent universal soft PU casters for smooth sliding without scratching marble or wood floors. Dual brake system locks the stand firmly in place after stepping down the brakes to prevent accidental sliding.

Q3: Is installation complicated?

A: Complete installation manuals and full set of accessories are provided. Ordinary staff can finish assembly within 30 minutes without professional tools. Universal mounting screws are adopted for easy follow-up adjustment.

Q4: The hotel corridor space is limited; will this stand take up too much space?

A: The base size of the mobile stand is controlled within 500mm×600mm, and the column thickness is only about 50mm, occupying less than 0.3 square meters of floor space. When not in use, it can be stored in warehouses or corners, and multiple stands can be stacked to save storage space.
