Commercial Display Stand
One-stop supporting solution for commercial screens. The vertical stone commercial display stand features solid craftsmanship and stable performance. It can be flexibly transformed into various installation and placement forms with comprehensive protective designs, adapting to diverse commercial layout scenarios for daily publicity, conference presentations and other applications. OEM customization and bulk drop-shipping services are available.
Commercial display stands are dedicated mounting support systems designed for digital signage, advertising players, information display screens and other commercial display devices, widely deployed in retail stores, enterprise lobbies, transportation hubs, medical institutions and other public spaces. Unlike household TV brackets, commercial display stands meet stricter standards for frequent use, long-hour operation, public safety and neat installation.
Our product line includes wall-mounted, floor-standing, ceiling-hung and mobile types, compatible with 32-inch to 86-inch commercial displays, supporting horizontal/vertical screen switching and multi-angle adjustment, delivering professional, safe and tidy mounting solutions for commercial clients.
Product Selection Guide
Step 1: Confirm Installation Location
|
Wall Condition |
Recommended Model |
Reason |
|
Concrete / Solid Brick Wall |
Wall-mounted (CM-W) |
Most stable with lowest cost |
|
Glass / Marble / Light Steel Keel |
Floor-standing (CM-F) or Mobile (CM-M) |
No wall damage |
|
Non-drillable / Rented Premises |
Mobile (CM-M) |
Zero structural damage |
|
Ceiling / High Mounting Points |
Tilt Ceiling-mounted (CM-T) |
Optimal overhead viewing angle |
Step 2: Confirm Usage Frequency
|
Usage Mode |
Recommended Model |
Reason |
|
Fixed position, long-term stationary |
Wall-mounted (CM-W) |
Space-saving and minimalist appearance |
|
Occasional repositioning within one room |
Floor-standing (CM-F) |
Minor position adjustment available |
|
Frequent relocation across rooms/sites |
Mobile (CM-M) |
Equipped with casters for easy transfer |
Step 3: Confirm Screen Size & Weight
|
Screen Size |
Required Load Capacity |
Recommended Models |
|
55–65 inch |
≥70kg |
All series |
|
65–75 inch |
≥80kg |
Mobile / Wall-mounted / Floor-standing |
|
75–86 inch |
≥80kg |
Reinforced Mobile / Reinforced Wall-mounted |
|
86-98寸 |
≥90kg |
Heavy-duty Mobile / Heavy-duty Floor-standing |
Why Specialized Stands Are Required for Commercial Scenarios
|
Commercial Scenario |
Drawbacks of Ordinary Household Brackets |
Solutions of Our Commercial Display Stands |
|
Conference Rooms (Daily Use) |
Sticky lifting, fast caster wear |
Industrial gas springs + high-resilience PU casters,≥10,000 lifting cycles service life |
|
Schools & Training Institutions |
Easy to topple when hit by students |
Widened low-center-of-gravity base, anti-toppling design, optional safety cables |
|
Hotel Lobbies (24/7 Operation) |
Cheap appearance, messy exposed cables |
Anodized aluminum frame + internal cable routing, elevates space grade |
|
Retail Stores & Advertising Screens |
Immovable, hard to relocate |
Standard universal casters for single-person transport anywhere |
|
Multi-site Roadshows |
Complicated assembly/disassembly, large transport footprint |
Quick-disassembly & foldable base, 5-minute assembly, 60% smaller transport volume |
|
Outdoor / Semi-outdoor Settings |
Prone to rust, poor weather resistance |
Outdoor powder coating,≥120-hour salt spray test resistance |
Core Features
1.Commercial-grade Load Bearing with Ample Safety Margin
Max load capacity: 90kg (compatible with 98-inch commercial displays)
Safety factor: 2.5x (90kg rated load vs. actual equipment weight of 25–40kg)
Material guarantee: 2.0–2.5mm thick cold-rolled steel / aerospace-grade aluminum alloy main beams
Compatible devices: Mainstream commercial brands including Hisense, MAXHUB, Huawei IdeaHub, Samsung, LG, Philips, etc.
2.Diverse Mounting Options for Customized Screen Solutions
| Installation Method | Key Advantages | Typical Applications |
| Mobile Cart Mount | Wheel-mounted for easy movement, height adjustment, and 360° rotation | Conference rooms, training rooms, multi-location shared use |
| Fixed Wall Mount | Wall-mounted design, space-saving, cost-effective | Exhibition halls, corridors, fixed information displays |
| Floor Stand Mount | No wall damage, movable with flexible position adjustment | Lobbies, reception areas, non-wall installation scenarios |
| Tilted Ceiling Mount | High-position installation, downward viewing angle, saves floor space | Restaurants, waiting halls, hospital queue display screens |
| Retractable Rotating Mount | Left-right rotation, front-back extension, adjustable viewing angles | Corner installations and applications requiring multi-angle viewing |
3.Hidden Cable Routing for Tidy Appearance
All models come with built-in cable channels inside columns
Power cords, HDMI cables and network cables can be fully concealed
Bottom cable outlet for connection to floor or wall sockets
Cable fixing buckles on the back of the stand to avoid messy wiring
Commercial value: Pass hotel/enterprise image acceptance inspection, enhance space professionalism
4.Silent Mobility, Floor Scratch-proof (Mobile Models)
Casters: 4/5-inch high-elastic PU silent wheels
Rolling noise:≤35 decibels (lower than ambient conference room noise)
Floor compatibility: No scratches on wood floors, marble, carpets and tiles
Brake system: 2 lockable casters for stable stationary placement
5.Anti-tip Design with Top Safety Priority (Mobile & Floor-standing Models)
Widened base: 800×600mm (20% wider than standard brackets)
Low center of gravity: Gravity height≤60cm, 50% higher stability
Optional safety cables for secondary fixation to walls or desks
Suitable for schools, kindergartens and high-foot-traffic public spaces
6.Height Adjustable to Fit All Viewing Perspectives
Lifting range: 110–170cm (screen center height from ground)
Adjustment methods: Pneumatic assistance / hand-twist locking
Applicable heights:
110cm: Seated viewing (training, video conferences)
140cm: Standing viewing (press conferences, speeches)
170cm: Bar counter / elevated display (restaurants, retail stores)
Technical Specifications
|
Parameter |
CM-M (Mobile) |
CM-W (Wall-mounted) |
CM-F (Floor-standing) |
CM-T (Tilt Ceiling-mounted) |
CM-S (Telescopic Rotatable) |
|
Compatible Screen Size |
55–98 inch |
55–98 inch |
55–98 inch |
55–86 inch |
55–86 inch |
|
Max Load Capacity |
90kg |
80kg |
80kg |
70kg |
70kg |
|
VESA Mount Holes |
200×200 to 800×6 |
Same as left |
Same as left |
Same as left |
Same as left |
|
Material |
Aluminum Alloy + SPCC Steel |
SPCC Steel |
SPCC Steel |
SPCC Steel |
SPCC Steel |
|
Main Material Thickness |
2.0mm |
1.8mm |
2.0mm |
1.8mm |
1.8mm |
|
Lifting Range |
110–170cm |
Fixed |
Fixed |
Fixed |
Fixed |
|
Tilt Angle |
-5°~ +15° |
0–5° |
0° |
-15°~ 0° |
-15°~ +15° |
|
Rotation Angle |
360° |
0° |
0° |
0° |
±90° |
|
Telescopic Distance |
N/A |
N/A |
N/A |
N/A |
30–50cm |
|
Caster Specs |
4 PU wheels×4 (2 lockable) |
N/A |
Adjustable Foot Pads |
N/A |
N/A |
|
Base Dimension |
800×600mm |
N/A |
600×500mm |
N/A |
N/A |
|
Color Options |
Silver / Black / White |
Black / White |
Black / White |
Black / White |
Black / White |
|
Net Weight |
Approx. 35kg |
Approx. 12kg |
Approx. 25kg |
Approx. 15kg |
Approx. 18kg |
|
Salt Spray Test Resistance |
≥72h |
≥72h |
≥72h |
≥72h |
≥72h |
Installation Steps
✅Wall-mounted Type
Mark drilling positions with a level and fasten wall plates with expansion bolts
Mount hooks on the rear of the display screen
Hang the screen onto wall plates and lock anti-theft screws
✅Floor-standing Type
Assemble base and vertical column, level via adjustable bottom foot pads
Fix mounting bracket to the screen rear
Hook screen onto column slots and lock safety latches
Route cables through internal vertical wire channels
✅Mobile Type
Same assembly steps as floor-standing type; equipped with universal lockable casters. Step on brakes after moving to target position.
✅Ceiling-mounted Type
Confirm load-bearing ceiling points (steel structure or additional suspension rods required)
Fasten ceiling base with expansion bolts
Connect suspension rods and screen bracket, adjust height and tilt angles
Applicable Scenarios & Matching Schemes
|
Scenario |
Recommended Model |
Standard Configuration |
Key Considerations |
|
Corporate Conference Rooms |
CM-M Mobile Cart |
75–86 inch + Camera Tray |
Mobility for shared use, video conference, concealed wiring |
|
Schools & Training Institutions |
Reinforced CM-M Mobile Cart |
65–75 inch + Safety Cables |
Anti-collision, adjustable height for seated & standing viewing |
|
Hotel Lobbies & Reception Areas |
CM-F Floor-standing |
75–86 inch + White Finish |
No wall renovation damage, elegant appearance, hidden cable routing |
|
Retail Stores & Advertising Displays |
CM-M Mobile Cart |
65–86 inch + Vertical Screen Mode |
Portable for multi-location rotation exhibition |
|
Hospital Waiting & Queuing Screens |
CM-T Tilt Ceiling-mounted |
55–75 inch Ceiling Installation |
Saves floor space, overhead downward viewing |
|
Restaurants & Bars |
CM-W Wall-mounted |
65–86 inch with tilt adjustment |
Fixed installation, oil stain resistance, space-saving |
|
Exhibition Halls & Museums |
CM-S Telescopic Rotatable |
65–86 inch |
Adjustable angles to fit varying visitor routes |
|
Temporary Exhibitions & Pop-up Stores |
Foldable CM-M Mobile Cart |
75-inch + Foldable Base |
Fast assembly/disassembly, reduced transport volume |
Competitor Comparison
|
Comparison Item |
Ordinary Household Brackets |
Our Commercial Display Stands |
|
Load Capacity |
50kg (frequently falsely labeled) |
80–90kg (genuine rating, 2.5x safety factor) |
|
Caster Service Life |
Ordinary PVC wheels, fast abrasion |
High-resilience PU wheels,≥10,000 pushing cycles |
|
Lifting Mechanism |
Multi-stage pin latch, labor-intensive |
Pneumatic assist, single-hand operation |
|
Cable Routing Design |
External binding straps, messy wiring |
Concealed vertical column cable channels, tidy layout |
|
Anti-toppling Function |
Minimal or no protection |
Widened base + low gravity center + optional safety cables |
|
Material Quality |
Thin ordinary steel, easy deformation |
Thickened cold-rolled steel / aerospace aluminum, deformation-free for 8 years |
|
Surface Treatment |
Basic paint coating, rust-prone |
Electrostatic powder coating / anodization,≥72h salt spray resistance |
|
Applicable Scenarios |
Household, temporary light use |
24/7 commercial operation, high-frequency usage |
|
Warranty Period |
Typically 1 year |
2-year structural warranty, 1-year accessory warranty |
FAQ
Q1: What is the difference between commercial display stands and household TV brackets?
A: Commercial stands prioritize anti-theft design, stability for long-hour operation, neat concealed wiring, multi-angle adjustment and compatibility with frequent power cycling for commercial environments. Household brackets focus on simple installation and low cost only.
Q2: Can the stand be installed on glass curtain walls or tiled walls?
A: Yes. Special glass clamps or tile-specific expansion tubes are required. Confirm the glass is tempered and verify its load-bearing capacity before installation; professional installation technicians are recommended.
Q3: Are tools required for horizontal/vertical screen switching?
A: Most models only need loosening hand-twist screws on both sides, rotating the screen 90°and re-tightening without tools. A hex wrench is required for a small number of economical models.
Q4: Can customized specifications be ordered for bulk engineering procurement?
A: Customized sizes and structures are available to meet personalized mounting demands of various projects.
