LCD 100-inch Vertical Hydraulic Bracket

LCD 100-inch vertical hydraulic bracket is an extra-heavy-duty support system designed for 100-inch LCD giant screens (also compatible with 102/105-inch models). Unlike brackets for 98-inch and smaller screens, a bare 100-inch screen usually weighs over 130 kg and stands nearly 2.2 meters tall, which cannot be safely supported by wall mounting alone. This product features a hybrid structure combining auxiliary wall load-bearing and floor support. Most vertical load is transferred to the ground, while the wall only serves to prevent tipping and fix positioning.

Materials & Craftsmanship

1. Main Frame:

Thickened and widened cold-rolled steel plates with reinforcing ribs for higher load capacity and torsion resistance without deformation.

2. Hydraulic System:

Industrial-grade dual hydraulic damping components offer even support, smooth lifting and silent buffering.

3. Hanging Plate Assembly:

Custom widened VESA vertical hanging plate for 100-inch screens, compatible with standard mounting holes for large-size displays.

4. Safety Protection:

Multiple anti-fall latches plus anti-slip shock-absorbing rubber pads to prevent accidental dropping.

5. Fixing Fittings:

National standard thickened and lengthened expansion bolts to evenly distribute wall stress for firmer installation.

Product Advantages

1. Customized for giant screens:

Optimized exclusively for 100-inch vertical mounting, more stable and well-fitted than universal brackets.

2. Labor-saving hydraulic system:

Effortless adjustment to protect the screen and its ports.

3. Low maintenance cost:

Quick-disassembly design operable without professional technicians.

4. Space-saving:

Wall-hugging vertical design with minimal horizontal footprint, ideal for lobbies, corridors and exhibition halls.

5. Wide applicability:

Works for conferences, exhibitions, shopping malls, hospitals, government offices, media industries and more.

Operation & Maintenance Cost Comparison with Traditional Brackets

Wall Requirements & Installation Specifications

Critical Safety Warning

A 100-inch screen weighs more than 90 kg. Improper wall types may cause screen falling, resulting in property loss and personal injury.

Permitted Wall Types (All requirements must be met simultaneously)

Prohibited Wall Types (Installation Strictly Forbidden)

Required Tools & Number of Installers

Installation Steps

1. Wall Inspection: Confirm the wall is solid concrete or brick with qualified thickness.

2. Positioning & Marking: Use a laser level to draw the vertical center line and mark 8 drilling points.

3. Drilling & Hole Cleaning: Drill holes at depth≥100 mm with an electric hammer, clear debris and insert M10 expansion tubes.

4. Base Fixation: Mount the wall base, tighten 8 expansion bolts step by step and check verticality.

5. VESA Hanging Plate Installation: Attach the widened VESA plate to the back of the 100-inch screen (compatible with hole patterns 600×400, 800×600, 900×600).

6. Preparations for Screen Hanging: Inspect hydraulic rods and safety latches; adjust the lifting platform to installation height.

7. Mount the Screen: Two workers lift the screen while one operator guides hooks to align with base slots and lower slowly.

8. Lock Safety Latches: Fasten main buckles, side safety locks and hand-twisted anti-tilt screws sequentially.

9. Cable Management & Adjustment: Route cables into the magnetic cable compartment and adjust tilt angle to the optimal viewing position.

10. Final Inspection: Shake the screen to confirm no looseness and check all latches.

Applicable Scenarios

Corporate Office

Large conference room screens, front desk welcome displays, corporate culture display walls

Commercial Display

Mall advertising screens, brand exhibition demo screens, store digital poster screens

Government & Public Services

Information release screens in government halls, hospital guide screens, exhibition venue guidance screens

Media & Live Streaming

Vertical giant screens for short video live streaming, self-media content displays, studio information screens

Education & Training

Campus bulletin screens, training room demo screens, interactive displays for training institutions
